| GB/T 5099 Seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(MPa) |
Test pressure(MPa) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-83-0.8-15T | 83 | 15 | 22.5 | 34CrMo4 | 1.7 | 0.8 | 230 | 1.4 | Type Approval |
| WGⅡ-83-1.8-15T | 83 | 15 | 22.5 | 34CrMo4 | 1.7 | 1.8 | 460 | 2.6 | Type Approval |
| WGⅡ-83-2.1-15T | 83 | 15 | 22.5 | 34CrMo4 | 1.7 | 2.1 | 525 | 2.9 | Type Approval |
| WGⅡ-104-3-17A | 104 | 17 | 25.5 | 35CrMo | 2.1 | 3 | 475 | 3.9 | Type Approval |
| WGⅡ-116.5-3-17A | 116.5 | 17 | 25.5 | 35CrMo | 2.4 | 3 | 385 | 3.9 | Type Approval |
| WGⅡ-116.5-4.5-17A | 116.5 | 17 | 25.5 | 35CrMo | 2.4 | 4.5 | 540 | 5.4 | Type Approval |
| WGⅡ-137-4.5、7.5-17A | 137 | 17 | 25.5 | 35CrMo | 2.8 | 4.5 | 425 | 5.4 | Type Approval |
| WGⅡ-137-7.5-17A | 137 | 17 | 25.5 | 35CrMo | 2.8 | 7.5 | 650 | 8 | Type Approval |
| WGⅡ-156-10.5-17A | 156 | 17 | 25.5 | 35CrMo | 3.2 | 10.5 | 700 | 11.4 | Type Approval |
| WMⅡ-108-2-15A | 108 | 15 | 22.5 | 37Mn | 2.8 | 2 | 320 | 3.6 | Type Approval |
| WMⅡ-108-3.6-15A | 108 | 15 | 22.5 | 37Mn | 2.8 | 3.6 | 525 | 6 | Type Approval |
| WMⅡ-140-6.7-15A | 140 | 15 | 22.5 | 37Mn | 3.6 | 6.7 | 595 | 9.7 | Type Approval |
| WMⅡ-140-10-15A | 140 | 15 | 22.5 | 37Mn | 3.6 | 10 | 835 | 13 | Type Approval |
| WGⅡ-178-10-15A | 178 | 15 | 22.5 | 35CrMo | 3.8 | 10 | 552 | 14 | Type Approval |
| WGⅡ-178-12-15A | 178 | 15 | 22.5 | 35CrMo | 3.8 | 12 | 642 | 15.5 | Type Approval |
| WGⅡ-178-14-15A | 178 | 15 | 22.5 | 35CrMo | 3.8 | 14 | 731 | 17 | Type Approval |
| WGⅡ-178-16-15A | 178 | 15 | 22.5 | 35CrMo | 3.8 | 16 | 820 | 18.5 | Type Approval |
| WGⅡ-178-18-15A | 178 | 15 | 22.5 | 35CrMo | 3.8 | 18 | 909 | 20 | Type Approval |
| WGⅡ-203-20-20A | 203 | 20 | 30 | 34CrMo4 | 4.9 | 20 | 820 | 26.5 | Type Approval |
| WMⅡ-219-40-15A | 219 | 15 | 22.5 | 37Mn | 5.7 | 40 | 1300 | 48 | Type Approval |
| WGⅡ-232-35-20A | 232 | 20 | 30 | 30CrMo | 6.4 | 35 | 1100 | 50.6 | Type Approval |
| WMⅡ-267-68-15A | 267 | 15 | 22.5 | 37Mn | 6.9 | 68 | 1500 | 78 | Type Approval |
| WMⅡ-267-70-15A | 267 | 15 | 22.5 | 37Mn | 6.9 | 70 | 1540 | 80 | Type Approval |
| WGⅡ-356-70-8A | 356 | 8 | 12 | 30CrMo | 4.3 | 70 | 885 | 50 | Type Approval |
| WGⅡ-356-90-8A | 356 | 8 | 12 | 30CrMo | 4.3 | 90 | 1100 | 60 | Type Approval |
| WGⅡ-356-120-8A | 356 | 8 | 12 | 30CrMo | 4.3 | 120 | 1420 | 75 | Type Approval |
Remarks: A indicates a concave bottom and T indicates a convex bottom.
| 84/525/EEC Seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-104.6-(1.7~4.81)-17.4T | 104.6 | 174 | 250 | 34CrMo4 | 2.3 | 3 | 470 | 3.63 | PED |
| WGⅡ-105-(1.7~4.81)-16.6(17.4)A | 105 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.3 | 1.7 | 320 | 3.2 | PED TPED |
| WGⅡ-105-(1.7~4.81)-16.6(17.4)A | 105 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.3 | 2 | 355 | 3.5 | PED TPED |
| WGⅡ-105-(1.7~4.81)-16.6(17.4)A | 105 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.3 | 2.7 | 445 | 4.1 | PED TPED |
| WGⅡ-105-(1.7~4.81)-16.6(17.4)A | 105 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.3 | 3 | 475 | 4.3 | PED TPED |
| WGⅡ-105-(1.7~4.81)-16.6(17.4)A | 105 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.3 | 3.5 | 540 | 4.8 | PED TPED |
| WGⅡ-105-(1.7~4.81)-17.4T | 105 | 174 | 250 | 34CrMo4 | 2.3 | 1.7 | 320 | 3.2 | PED |
| WGⅡ-105-(1.7~4.81)-17.4T | 105 | 174 | 250 | 34CrMo4 | 2.3 | 2 | 355 | 3.5 | PED |
| WGⅡ-105-(1.7~4.81)-17.4T | 105 | 174 | 250 | 34CrMo4 | 2.3 | 2.7 | 445 | 4.1 | PED |
| WGⅡ-105-(1.7~4.81)-17.4T | 105 | 174 | 250 | 34CrMo4 | 2.3 | 3 | 475 | 4.3 | PED |
| WGⅡ-105-(1.7~4.81)-17.4T | 105 | 174 | 250 | 34CrMo4 | 2.3 | 3.5 | 540 | 4.8 | PED |
| WGⅡ-116-(2.64~4.84)-17.4A | 116 | 174 | 250 | 34CrMo4 | 2.59 | 3 | 385 | 5.8 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 4.5 | 440 | 6.5 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 5 | 460 | 6.7 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 6 | 550 | 7.7 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 7 | 625 | 8.5 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 7.5 | 655 | 8.8 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 9 | 770 | 10 | PED |
| WGⅡ-138-(4.32~11.82)-17.4A | 138 | 174 | 250 | 34CrMo4 | 3 | 10 | 845 | 10.8 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 4.5 | 440 | 6.5 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 5 | 460 | 6.7 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 6 | 550 | 7.7 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 7 | 625 | 8.5 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 7.5 | 655 | 8.8 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 9 | 770 | 10 | PED |
| WGⅡ-138-(4.32~11.82)-17.4T | 138 | 174 | 250 | 34CrMo4 | 3 | 10 | 845 | 10.8 | PED |
Remarks: A indicates a concave bottom and T indicates a convex bottom.
| EN 1964-1 Transportable gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.040 | 135 | 0.19 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.047 | 150 | 0.20 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.054 | 165 | 0.22 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.067 | 195 | 0.25 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.074 | 208 | 0.26 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.080 | 223 | 0.28 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.100 | 267 | 0.33 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.114 | 300 | 0.37 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.120 | 315 | 0.38 | TPED |
| WMⅡ-28-(0.035~0.250)-19.3T | 28 | 193 | 290 | ST52 | 1.5 | 0.148 | 370 | 0.45 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.074 | 145 | 0.23 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.080 | 148 | 0.24 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.100 | 175 | 0.29 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.107 | 182 | 0.30 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.120 | 200 | 0.33 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.134 | 218 | 0.36 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.147 | 240 | 0.39 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.154 | 245 | 0.40 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.160 | 255 | 0.41 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.174 | 275 | 0.44 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.180 | 285 | 0.46 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.200 | 305 | 0.51 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.240 | 365 | 0.59 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.267 | 405 | 0.67 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.280 | 415 | 0.68 | TPED |
| WMⅡ-35-(0.070~0.300)-19.3T | 35 | 193 | 290 | ST52 | 1.7 | 0.300 | 458 | 0.73 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.160 | 205 | 0.36 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.200 | 243 | 0.44 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.227 | 270 | 0.48 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.240 | 280 | 0.50 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.254 | 320 | 0.58 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.280 | 325 | 0.59 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.300 | 365 | 0.66 | TPED |
| WMⅡ-40-(0.104~0.300)-19.3T | 40 | 193 | 290 | ST52 | 1.95 | 0.400 | 440 | 0.80 | TPED |
| WGⅡ-116-(2.6~6.6)-20A | 116 | 200 | 300 | 34CrMo4 | 2.59 | 2.5 | 335 | 4.2 | TPED |
| WGⅡ-116-(2.6~6.6)-20A | 116 | 200 | 300 | 34CrMo4 | 2.59 | 2.7 | 355 | 4.4 | TPED |
| WGⅡ-116-(2.6~6.6)-20A | 116 | 200 | 300 | 34CrMo4 | 2.59 | 3 | 385 | 4.6 | TPED |
| WGⅡ-200-(8~14)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 10.7 | 490 | 15.8 | TPED |
| WGⅡ-200-(8~14)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 13.4 | 580 | 17.9 | TPED |
| WGⅡ-200-(8~14)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 14 | 610 | 18.6 | TPED |
| WGⅡ-200-(14~31.5)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 15 | 635 | 19.1 | TPED |
| WGⅡ-200-(14~31.5)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 16 | 685 | 20.3 | TPED |
| WGⅡ-200-(14~31.5)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 20 | 820 | 23.4 | TPED |
| WGⅡ-200-(14~31.5)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 27 | 1095 | 29 | TPED |
| WGⅡ-200-(14~31.5)-20A | 200 | 200 | 300 | 34CrMo4 | 4.47 | 30 | 1200 | 31.5 | TPED |
| WGⅡ-203-13.4-16.6A | 203 | 166 | 250 | 34CrMo4 | 3.63 | 13.4 | 570 | 19 | TPED |
| WGⅡ-203-15-16.6A | 203 | 166 | 250 | 34CrMo4 | 3.63 | 15 | 615 | 20.5 | TPED |
| WGⅡ-232-18-16.6A | 232 | 166 | 250 | 34CrMo4 | 4.47 | 18 | 580 | 25 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 33.5 | 1060 | 41 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 40 | 1230 | 46 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 40.5 | 1245 | 46.5 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 43 | 1300 | 49 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 50 | 1500 | 55 | TPED |
| WGⅡ-229-(33.5~77.5)-20A | 229 | 200 | 300 | 34CrMo4 | 5.2 | 50 | 1500 | 55 | Type Approval |
| WGⅡ-232-18-16.6A | 232 | 166 | 250 | 34CrMo4 | 4.47 | 18 | 580 | 25 | TPED |
Remarks: A indicates a concave bottom and T indicates a convex bottom.
| EN ISO 9809-1 Refillable seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-83-(0.65~1.7)-20T | 83 | 200 | 300 | 34CrMo4 | 2 | 0.8 | 230 | 1.36 | TPED KGS |
| WGⅡ-83-(0.65~1.7)-20T | 83 | 200 | 300 | 34CrMo4 | 2 | 1 | 275 | 1.6 | |
| WGⅡ-101.6-1.1-17.4T | 101.6 | 174 | 250 | 34CrMo4 | 1.94 | 1.1 | 220 | 1.9 | PED KGS |
| WZⅡ-101.6-(1.6~4.9)-17.4A | 101.6 | 174 | 250 | ST52 | 3.1 | 3 | 475 | 4.26 | PED |
| WGⅡ-101.6-1.1-17.4T | 101.6 | 174 | 250 | 34CrMo4 | 1.94 | 1.1 | 225 | 1.95 | PED KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 1.7 | 320 | 3.1 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 1.9 | 330 | 3.2 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2 | 350 | 3.3 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.3 | 395 | 3.6 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.5 | 415 | 3.7 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.7 | 440 | 3.9 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3 | 475 | 4.1 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3.5 | 540 | 4.5 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)A | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3.8 | 580 | 4.8 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 1.7 | 320 | 3.1 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 1.9 | 330 | 3.2 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2 | 350 | 3.3 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.3 | 395 | 3.6 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.5 | 415 | 3.7 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 2.7 | 440 | 3.9 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3 | 480 | 4.1 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3.5 | 540 | 4.5 | PED 、TPED、KGS |
| WGⅡ-103-(1.7~4.35)-16.6(17.4)T | 103 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 1.97 | 3.8 | 580 | 4.8 | PED 、TPED、KGS |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 1.9 | 335 | 3.2 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 2 | 350 | 3.3 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 2.67 | 440 | 3.9 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 3 | 485 | 4.1 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 3.5 | 530 | 4.5 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)A | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 4 | 610 | 4.9 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 1.9 | 335 | 3.2 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 2 | 350 | 3.3 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 2.67 | 440 | 3.9 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 3 | 485 | 4.1 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 3.5 | 530 | 4.5 | PED TPED |
| WGⅡ-103.5-(1.87~4.55)-21(21.6)T | 103.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 2.43 | 4 | 610 | 4.9 | PED TPED |
| WGⅡ-105-(1.87~4.56)-21A | 105 | 210 | 315 | 34CrMo4 | 2.51 | 1.8 | 320 | 3.2 | TPED |
| WGⅡ-105-(1.87~4.56)-21A | 105 | 210 | 315 | 34CrMo4 | 2.51 | 2 | 355 | 3.5 | TPED |
| WGⅡ-105-(1.87~4.56)-21A | 105 | 210 | 315 | 34CrMo4 | 2.51 | 2.5 | 410 | 3.9 | TPED |
| WGⅡ-105-(1.87~4.56)-21A | 105 | 210 | 315 | 34CrMo4 | 2.51 | 2.67 | 440 | 4.1 | TPED |
| WGⅡ-105-(1.87~4.56)-21A | 105 | 210 | 315 | 34CrMo4 | 2.51 | 3 | 475 | 4.4 | TPED |
| WGⅡ-105-3-21T | 105 | 210 | 315 | 34CrMo4 | 2.51 | 3 | 475 | 4.4 | TPED KGS |
| WGⅡ-105-(1.7~4.8)-16.6T | 105 | 166 | 250 | 34CrMo4 | 2.3 | 2 | 350 | 3.5 | TPED |
| WGⅡ-105-(1.7~4.8)-16.6T | 105 | 166 | 250 | 34CrMo4 | 2.3 | 3 | 475 | 4.3 | TPED |
| WGⅡ-105-(1.87~4.55)-21.6A | 105 | 216 | 315 | 34CrMo4 | 2.51 | 1.8 | 320 | 3 | PED |
| WGⅡ-105-(1.87~4.55)-21.6A | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2 | 355 | 3.1 | PED |
| WGⅡ-105-(1.87~4.55)-21.6A | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2.5 | 410 | 3.7 | PED |
| WGⅡ-105-(1.87~4.55)-21.6A | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2.67 | 440 | 3.9 | PED |
| WGⅡ-105-(1.87~4.55)-21.6A | 105 | 216 | 315 | 34CrMo4 | 2.51 | 3 | 475 | 4.1 | PED |
| WGⅡ-105-(1.87~4.55)-21.6T | 105 | 216 | 315 | 34CrMo4 | 2.51 | 1.8 | 320 | 3 | PED |
| WGⅡ-105-(1.87~4.55)-21.6T | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2 | 355 | 3.1 | PED |
| WGⅡ-105-(1.87~4.55)-21.6T | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2.5 | 410 | 3.7 | PED |
| WGⅡ-105-(1.87~4.55)-21.6T | 105 | 216 | 315 | 34CrMo4 | 2.51 | 2.67 | 440 | 3.9 | PED |
| WGⅡ-105-(1.87~4.55)-21.6T | 105 | 216 | 315 | 34CrMo4 | 2.51 | 3 | 475 | 4.1 | PED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 4.5 | 430 | 5.8 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5 | 465 | 6.0 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5.3 | 485 | 6.2 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5.5 | 500 | 6.4 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 7 | 625 | 7.6 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 7.5 | 650 | 7.8 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 8 | 690 | 8.2 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 8.4 | 730 | 8.6 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)A | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 9 | 765 | 8.9 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 4.5 | 430 | 5.8 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5 | 475 | 6.0 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5.3 | 495 | 6.2 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 5.5 | 510 | 6.4 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 7 | 635 | 7.6 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 7.5 | 660 | 7.8 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 8 | 700 | 8.2 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 8.4 | 740 | 8.6 | PED TPED |
| WGⅡ-135.6-(4.32~10.68)-16.6(17.4)T | 135.6 | 166(TPED) 174(PED) |
250 | 34CrMo4 | 2.59 | 9 | 775 | 8.9 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 4.7 | 440 | 5.9 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 5 | 460 | 6.8 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 5.4 | 485 | 7.1 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 6.67 | 600 | 8.5 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 7.5 | 660 | 9.2 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 8 | 700 | 9.6 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)A | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 10 | 845 | 11.5 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 4.7 | 440 | 5.9 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 5 | 460 | 6.8 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 5.4 | 485 | 7.1 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 6.67 | 600 | 8.5 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 7.5 | 660 | 9.2 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 8 | 700 | 9.6 | PED TPED |
| WGⅡ-136.5-(4.47~11)-21(21.6)T | 136.5 | 210(TPED) 216(PED) |
315 | 34CrMo4 | 3.21 | 10 | 845 | 11.5 | PED TPED |
| WGⅡ-137-(3.5~4.2)-22A | 137 | 216 | 315 | 34CrMo4 | 3.3 | 3.7 | 370 | 5.9 | PED KGS |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 4.5 | 440 | 6.5 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 5 | 460 | 6.7 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 6 | 550 | 7.7 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 7 | 625 | 8.5 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 7.5 | 655 | 8.8 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 9 | 770 | 10 | PED |
| WGⅡ-138-(3.5~12)-17.4A | 138 | 174 | 250 | 34CrMo4 | 2.7 | 10 | 845 | 10.8 | PED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 4.5 | 440 | 6.5 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 5 | 460 | 6.7 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 6 | 550 | 7.7 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 7 | 625 | 8.5 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 7.5 | 655 | 8.8 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 9 | 770 | 10 | TPED |
| WGⅡ-138-(4.3~12)-16.6A | 138 | 166 | 250 | 34CrMo4 | 2.7 | 10 | 845 | 10.8 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 4.5 | 440 | 6.5 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 5 | 460 | 6.7 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 6 | 550 | 7.7 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 7 | 625 | 8.5 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 7.5 | 655 | 8.8 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 9 | 770 | 10 | TPED |
| WGⅡ-138-(4.2~11.9)-16.6T | 138 | 166 | 250 | 34CrMo4 | 2.7 | 10 | 845 | 10.8 | TPED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 5 | 460 | 6.8 | PED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 5.4 | 485 | 7.1 | PED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 6.67 | 600 | 8.5 | PED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 7 | 625 | 8.9 | PED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 8 | 695 | 9.6 | PED |
| WGⅡ-138-(4.47~11)-21.6A | 138 | 216 | 315 | 34CrMo4 | 3.3 | 10 | 845 | 11.5 | PED |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 5 | 460 | 6.8 | TPED KGS |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 5.4 | 485 | 7.1 | TPED KGS |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 6.67 | 600 | 8.5 | TPED KGS |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 7 | 625 | 8.9 | TPED KGS |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 8 | 695 | 9.6 | TPED KGS |
| WGⅡ-138-(4.47~11)-21A | 138 | 210 | 315 | 34CrMo4 | 3.3 | 10 | 845 | 11.5 | TPED KGS |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 5 | 460 | 6.8 | PED |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 5.4 | 485 | 7.1 | PED |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 6.67 | 600 | 8.5 | PED |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 7 | 625 | 8.9 | PED |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 8 | 695 | 9.6 | PED |
| WGⅡ-138-(4.47~11)-21.6T | 138 | 216 | 315 | 34CrMo4 | 3.3 | 10 | 845 | 11.5 | PED |
| WZⅡ-139.7-(4.3~11.9)-17.4A | 139.7 | 174 | 250 | ST52 | 4.2 | 5 | 420 | 8.6 | PED |
| WZⅡ-139.7-(4.3~11.9)-17.4A | 139.7 | 174 | 250 | ST52 | 4.2 | 6 | 500 | 9.9 | PED |
| WZⅡ-139.7-(4.3~11.9)-17.4A | 139.7 | 174 | 250 | ST52 | 4.2 | 7 | 580 | 11.3 | PED |
| WZⅡ-139.7-(4.3~11.9)-17.4A | 139.7 | 174 | 250 | ST52 | 4.2 | 7.5 | 660 | 12.6 | PED |
| WZⅡ-139.7-(4.3~11.9)-17.4A | 139.7 | 174 | 250 | ST52 | 4.2 | 8 | 740 | 14 | PED |
| WZⅡ-139.7-(4.3~23)-16.6A | 139.7 | 166 | 250 | 37Mn | 5 | 15 | 1270 | 23 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 5 | 490 | 8.1 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 6 | 560 | 9.3 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 7 | 640 | 10.8 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 8 | 720 | 12.1 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 9 | 800 | 13.5 | PED |
| WGⅡ-139.7-(4~10)-31.4T | 139.7 | 31.4 | 450 | 34CrMo4 | 4.4 | 10 | 880 | 14.8 | PED |
| WGⅡ-140-(4.34~14)-21T | 140 | 210 | 315 | 34CrMo4 | 3.4 | 8 | 710 | 10.8 | TPED |
| WGⅡ-140-(4.34~14)-21T | 140 | 210 | 315 | 34CrMo4 | 3.4 | 9 | 780 | 11.6 | TPED |
| WGⅡ-140-(4.34~14)-21T | 140 | 210 | 315 | 34CrMo4 | 3.4 | 10 | 855 | 12.6 | TPED |
| WGⅡ-140-(4.34~14)-21T | 140 | 210 | 315 | 34CrMo4 | 3.4 | 13.4 | 1100 | 14.6 | TPED |
| WGⅡ-140-(4.34~14)-21T | 140 | 210 | 315 | 34CrMo4 | 3.4 | 14 | 1140 | 15.1 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 6.8 | 505 | 8.6 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 7.5 | 540 | 9.1 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 8 | 570 | 9.5 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 9 | 630 | 10.4 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 10 | 685 | 11.1 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 10.5 | 700 | 11.3 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 11 | 740 | 11.9 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 13.5 | 890 | 14 | PED |
| WGⅡ-156-(6.2~15.2)-16.6A | 156 | 174 | 250 | 34CrMo4 | 3 | 15 | 980 | 15.4 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 6.8 | 505 | 8.6 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 7.5 | 540 | 9.1 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 8 | 570 | 9.5 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 9 | 630 | 10.4 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 10 | 685 | 11.1 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 10.5 | 700 | 11.3 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 11 | 740 | 11.9 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 13.5 | 890 | 14 | PED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 174 | 250 | 34CrMo4 | 3 | 15 | 980 | 15.4 | PED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 6.8 | 505 | 8.6 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 7.5 | 540 | 9.1 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 8 | 570 | 9.5 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 9 | 630 | 10.4 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 10 | 685 | 11.1 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 10.5 | 700 | 11.3 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 11 | 740 | 11.9 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 13.5 | 890 | 14 | TPED |
| WGⅡ-156-(6.5~15)-16.6A | 156 | 166 | 250 | 34CrMo4 | 3 | 15 | 980 | 15.4 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 6.8 | 505 | 8.6 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 7.5 | 540 | 9.1 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 8 | 570 | 9.5 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 9 | 630 | 10.4 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 10 | 685 | 11.1 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 10.5 | 700 | 11.3 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 11 | 740 | 11.9 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 13.5 | 890 | 14 | TPED |
| WGⅡ-156-(6.2~15.2)-16.6T | 156 | 166 | 250 | 34CrMo4 | 3 | 15 | 980 | 15.4 | TPED |
| WGⅡ-156-(6.27~16)-20A | 156 | 200 | 300 | 34CrMo4 | 3.45 | 10 | 685 | 11.5 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 6.8 | 450 | 11 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 7.5 | 485 | 11.7 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 8 | 515 | 12.3 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 9 | 570 | 13.4 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 10 | 630 | 14.7 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 10.2 | 635 | 14.8 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 11 | 680 | 15.7 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 12 | 735 | 16.8 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 13.4 | 810 | 18.4 | TPED |
| WGⅡ-165-(6~18.5)-16.6A | 165 | 166 | 250 | 34CrMo4 | 3.2 | 15 | 900 | 20.2 | TPED |
| WGⅡ-165-(7.7~20.5)-20T | 165 | 200 | 300 | 34CrMo4 | 3.8 | 13.4 | 810 | 17.1 | TPED |
| WGⅡ-165-(7.7~20.5)-20T | 165 | 200 | 300 | 34CrMo4 | 3.8 | 14 | 845 | 17.8 | TPED |
| WGⅡ-165-(7.7~20.5)-20T | 165 | 200 | 300 | 34CrMo4 | 3.8 | 15 | 900 | 19 | TPED |
| WGⅡ-165-(7.7~20.5)-20T | 165 | 200 | 300 | 34CrMo4 | 3.8 | 16 | 950 | 20 | TPED |
| WGⅡ-165-(7.7~20.5)-20T | 165 | 200 | 300 | 34CrMo4 | 3.8 | 20 | 1170 | 24.5 | TPED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 7 | 420 | 11.5 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 7.5 | 445 | 12.1 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 8 | 465 | 12.5 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 9 | 500 | 13.3 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 10 | 550 | 14.3 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 11 | 598 | 15.4 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 12 | 640 | 16.3 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 13.4 | 710 | 17.8 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 14 | 730 | 18.3 | PED |
| WGⅡ-178-(6~19)-20.9A | 178 | 209 | 300 | 34CrMo4 | 3.9 | 15 | 780 | 19.4 | PED |
| WGⅡ-178-(1.5~10)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 7 | 420 | 11.5 | TPED |
| WGⅡ-178-(1.5~10)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 7.5 | 445 | 12.1 | TPED |
| WGⅡ-178-(1.5~10)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 8 | 465 | 12.5 | TPED |
| WGⅡ-178-(1.5~10)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 9 | 500 | 13.3 | TPED |
| WGⅡ-178-(1.5~10)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 10 | 550 | 14.3 | TPED |
| WGⅡ-178-(10~22.4)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 11 | 598 | 15.4 | TPED |
| WGⅡ-178-(10~22.4)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 12 | 640 | 16.3 | TPED |
| WGⅡ-178-(10~22.4)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 13.4 | 710 | 17.8 | TPED |
| WGⅡ-178-(10~22.4)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 14 | 730 | 18.3 | TPED |
| WGⅡ-178-(10~22.4)-20A | 178 | 200 | 300 | 34CrMo4 | 4.1 | 15 | 780 | 19.4 | TPED |
| WZⅡ-232-(21~62.8)-16.6A | 232 | 166 | 250 | 37Mn | 5.0 | 40 | 1190 | 45 | Type Approval |
| WZⅡ-232-(21~62.8)-16.6A | 232 | 166 | 250 | 37Mn | 5.0 | 46 | 1350 | 50 | Type Approval |
| WGⅡ-232-(21~77.5)-20A | 232 | 200 | 300 | 34CrMo4 | 5.2 | 50 | 1460 | 57 | Type Approval |
| WZⅡ-232-(10~73)-16.6A | 232 | 166 | 250 | 37Mn | 5.3 | 26 | 810 | 32 | TPED |
| WZⅡ-232-(10~73)-16.6A | 232 | 166 | 250 | 37Mn | 5.3 | 40 | 1185 | 45 | TPED KGS |
| WZⅡ-232-(10~73)-16.6A | 232 | 166 | 250 | 37Mn | 5.3 | 47 | 1400 | 52 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.6A | 267 | 166 | 250 | 37Mn | 6.3 | 32.5 | 801 | 39 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.6A | 267 | 166 | 250 | 37Mn | 6.3 | 40 | 945 | 46 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.6A | 267 | 166 | 250 | 37Mn | 6.3 | 68 | 1500 | 70 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.6A | 267 | 166 | 250 | 37Mn | 6.3 | 80 | 1725 | 80 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.6A | 267 | 166 | 250 | 37Mn | 6.3 | 82.5 | 1790 | 83 | TPED KGS |
| WZⅡ-267-(32.5~106.1)-16.3A | 267 | 163 | 245 | 37Mn | 6.3 | 68 | 1480 | 70 | CCS |
| WZⅡ-279-(36.5~106.5)-16.6A | 279 | 166 | 250 | 37Mn | 6.3 | 82.5 | 1625 | 85 | TPED KGS |
| WZⅡ-279-(36.5~106.5)-16.6A | 279 | 166 | 250 | 37Mn | 6.3 | 87 | 1705 | 89 | TPED KGS |
| WZⅡ-279-(13.8~124)-16.3A | 279 | 163 | 245 | 37Mn | 6.3 | 80 | 1615 | 83 | CCS |
| WGⅡ-279-(37~124)-20A | 279 | 200 | 300 | 34CrMo4 | 6.3 | 80 | 1615 | 90 | TPED |
| WGⅡ-279-(37~124)-20A | 279 | 200 | 300 | 34CrMo4 | 6.3 | 67 | 1395 | 80 | TPED |
| WGⅡ-279-(50~125)-20A | 279 | 200 | 300 | 34CrMo4 | 6.3 | 80 | 1615 | 90 | Type Approval |
| WGⅡ-279-(13~94.7)-30A | 279 | 300 | 451 | 34CrMo4 | 8.5 | 84 | 1720 | 118 | TPED KGS |
| WGⅡ-356-(56~161)-16.6A | 356 | 166 | 250 | 34CrMo4 | 6.5 | 140 | 1690 | 134 | TPED KGS |
Remarks: A indicates a concave bottom and T indicates a convex bottom.
| EN ISO 9809-2 Refillable seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 15 | 520 | 20 | TPED |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 16 | 540 | 20.5 | TPED |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 18 | 590 | 21.5 | TPED |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 20 | 645 | 23 | TPED |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 40 | 1180 | 37.5 | TPED |
| WGⅡ-229-(11~70)-20A | 229 | 200 | 300 | 34CrMo4 | 4.3 | 50 | 1450 | 44.5 | TPED |
| WGⅡ-229-(11~70)-30A | 229 | 300 | 451 | 34CrMo4 | 6.4 | 30 | 950 | 44 | TPED |
| WGⅡ-229-(11~70)-30A | 229 | 300 | 451 | 34CrMo4 | 6.4 | 50 | 1510 | 64 | TPED |
| WGⅡ-267-(21~123)-20A | 267 | 200 | 300 | 34CrMo4 | 5.65 | 80 | 1710 | 79 | TPED |
| WGⅡ-267-(21~106)-30A | 267 | 300 | 451 | 34CrMo4 | 7.5 | 80 | 1780 | 107 | TPED |
| WGⅡ-356-(31~156)-20A | 356 | 200 | 300 | 34CrMo4 | 7.4 | 80 | 1025 | 89 | TPED |
| WGⅡ-356-(31~156)-20A | 356 | 200 | 300 | 34CrMo4 | 7.4 | 140 | 1690 | 137 | TPED |
| WGⅡ-356-(28~158)-30A | 356 | 300 | 451 | 34CrMo4 | 9.7 | 80 | 1090 | 119 | TPED |
| WGⅡ-356-(28~158)-30A | 356 | 300 | 451 | 34CrMo4 | 9.7 | 140 | 1770 | 182 | TPED |
Remarks: A indicates a concave bottom.
| ISO 9809-3 Refillable seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WMⅡ-108-2-16.6A | 108 | 166 | 250 | 37Mn | 2.8 | 2 | 320 | 3.6 | No Certification |
| WMⅡ-108-3-16.6A | 108 | 166 | 250 | 37Mn | 2.8 | 3 | 450 | 5.3 | No Certification |
| WMⅡ-108-3.5-16.6A | 108 | 166 | 250 | 37Mn | 2.8 | 3.5 | 515 | 5.6 | No Certification |
| WMⅡ-108-5-16.6A | 108 | 166 | 250 | 37Mn | 2.8 | 5 | 708 | 7.5 | No Certification |
| WMⅡ-140-(4.6~11.8)-16.6A | 140 | 166 | 250 | 37Mn | 3.6 | 5 | 465 | 7.9 | Type Approval |
| WMⅡ-140-(4.6~11.8)-16.6A | 140 | 166 | 250 | 37Mn | 3.6 | 6 | 540 | 9 | Type Approval |
| WMⅡ-140-(4.6~11.8)-16.6A | 140 | 166 | 250 | 37Mn | 3.6 | 6.7 | 580 | 9.6 | Type Approval |
| WMⅡ-140-(4.6~11.8)-16.6A | 140 | 166 | 250 | 37Mn | 3.6 | 10 | 835 | 13.4 | Type Approval |
| WMⅡ-140-(4~23)-16.6T | 140 | 166 | 250 | 37Mn | 5 | 15 | 1270 | 23 | TPED |
| WMⅡ-159-10-16.6A | 159 | 166 | 250 | 37Mn | 4.1 | 10 | 662 | 14.1 | No Certification |
| WMⅡ-159-13.4-16.6A | 159 | 166 | 250 | 37Mn | 4.1 | 13.4 | 865 | 17.4 | No Certification |
| WMⅡ-159-15-16.6A | 159 | 166 | 250 | 37Mn | 4.1 | 15 | 970 | 20 | No Certification |
| WMⅡ-159-16-16.6A | 159 | 166 | 250 | 37Mn | 4.1 | 16 | 1030 | 21 | No Certification |
| WMⅡ-219-13.4-16.6A | 219 | 166 | 250 | 37Mn | 5.6 | 13.4 | 510 | 22 | No Certification |
| WMⅡ-219-48-16.6A | 219 | 166 | 250 | 37Mn | 5.6 | 48 | 1550 | 56 | No Certification |
| WMⅡ-219-50-16.6A | 219 | 166 | 250 | 37Mn | 5.6 | 50 | 1610 | 58 | No Certification |
| WMⅡ-219-(25~62.5)-15A | 219 | 150 | 225 | 37Mn | 5 | 33.5 | 1140 | 42 | Type Approval |
| WMⅡ-219-(25~62.5)-15A | 219 | 150 | 225 | 37Mn | 5 | 40 | 1300 | 48 | Type Approval |
| WMⅡ-232-(30.5~73.5)-16.6A | 232 | 166 | 250 | 37Mn | 6.3 | 47 | 1400 | 60 | Type Approval |
| WMⅡ-267-(43~105.5)-15A | 267 | 150 | 225 | 37Mn | 6.1 | 68 | 1500 | 77 | Type Approval |
Remarks: A indicates a concave bottom and T indicates a convex bottom.
| DOT 3AA & UN ISO 9809-1 Refillable seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar/psi) |
Test pressure(bar/psi) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-133-(3~3.9)-13.9A | 133 | 139/2015 | 232/3365 | 30CrMo | 3 | 3.6 | 375 | 5.2 | 3AA & UN ISO 9809-1 |
Remarks: A indicates a concave bottom.
| ISO 9809-4 Refillable seamless stainless steel cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| BWⅡ-232-(20~62)-6.6A | 232 | 6.6 | 10 | S31603 | 6.1 | 40 | 1210 | 55 | TPED & KR |
Remarks: A indicates a concave bottom.
| DOT-3AA Seamless steel gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar/psi) |
Test pressure(bar/psi) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WGⅡ-133-(3.0~3.9)-13.9A | 133 | 139/2015 | 232/3365 | 30CrMo | 0.118/3.0 | 3.6 | 375 | 5.2 | DOT |
Remarks: A indicates a concave bottom.
| EN 12205 Transportable gas cylinders－Non refillable metallic gas cylinders | |||||||||
| Type |
Outside Diameter(mm) |
Working pressure(bar) |
Test pressure(bar) |
Material |
Design wall thickness(mm) |
Nominal water capacity (L) |
Cylinder height(mm) |
Nominal weight(kg) |
Certificate |
| WMⅡ-70-0.6-11T | 70 | 110 | 180 | No. 20 steel | 2.8 | 0.6 | 210 | 1.34 | TPED |
| WMⅡ-70-0.94-11T | 70 | 110 | 180 | No. 21 steel | 2.8 | 0.94 | 319 | 1.88 | TPED |
| WMⅡ-70-1.45-11T | 70 | 110 | 180 | No. 22 steel | 2.8 | 1.45 | 478 | 2.67 | TPED |
Remarks: T means convex bottom.
