Drawing | Inlet thread | Dip tube thread | Outlet thread | Pressure gauge thread | Working pressure(bar) | Test pressure(bar) | PRD Pressure(bar) | Working temperature | Certificate |
WN50-09-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09A-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09B-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09C-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09D-0Rev.0 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09E-0Rev.0 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09F-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09G-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09L-0Rev.2 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09K-0Rev.0 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09T-0Rev.0 | M30x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
WN50-09S-0Rev.0 | M24x1.5 | M16x1.5 | G1/8 | M10x1 | 26 | 38 | 19~26 | -30℃~+60℃ | CE |
